The edge gasket is permanently fixed on the long glass plate to ensure the precise alignment of
the glass plate and prevent glue leakage;
The cam-lock gel frame is easy to operate and can precisely align the glass plate on any plane;
Special plastic electrophoresis combs do not inhibit gel polymerization Built-in ridges avoid air
contact;
Ensure uniform gel polymerization;
The long glass plate with edge gasket is thickened so that the glass plate is not easy to break;
The one-piece gel filling rack is arranged in parallel, and two gels can be observed at the same
time;
SDS-PAGE electrophoresis time: 45 minutes (200V constant voltage);
High-purity platinum electrode wire to achieve the best electrical conductivity;
The parameters and accessories of this product are fully compatible with imported similar
products;
This product is compatible with DL-ZY03 for blot transfer;
Features
•
•
•
•
•
•
•
•
•
•
DL-MINI04
Vertical electrophoresis tank
D
lectrophoresis
E
Standard configuration
Technical Parameters
Number of gels: 1-4 pieces
Gel thickness: 0.75, 1, 1.5mm
Option tooth number of sample comb: 10, 15 teeth
Glass size: short glass plate (10.1×7.3cm); long glass plate (10.1×8.2cm)
Gel size: hand-cast gel (8.3×7.3cm); precast gel (8.6×6.8cm)
Lid with cables
Bottom tank
Electrode main core
Electrode sub-core
Gel glass thick plate
Gel Glass thin plate
10-well comb
Gel casing stand
Casing frame
Single Gel Baffle
Gel Releaser
Set
pc
Set
Set
pc
pc
pc
pc
pc
pc
pc
1
1
1
1
5
5
5
2
4
1
1
Name Unit Quantity
Prepare 1.0mm thick gel by default
