This product is a device for vertical electrophoresis of a small amount of nucleic acid and
protein samples
The integrated design of the glass plate and the gasket ensures no glue leakage
Can run two 8.3×7.3cm gels at the same time
Special glue making device, simple and reliable operation
Silicone sealing pad, anti-aging and durable
Open the cover and cut off the power to ensure the safety of the experiment
The limit function of the upper cover ensures that the positive and negative electrodes will
not be installed incorrectly
99.99% high-purity platinum electrode, the best electrical conductivity, anti-corrosion and
aging
Equipped with a variety of thickness specifications rubber plate and sample comb to meet
different experimental requirements
It can be used together with DL-ZY02
Features
•
•
•
•
•
•
•
•
•
•
DL-Mini01
Vertical electrophoresis tank (double plate)
D
lectrophoresis
E
Standard configuration
Technical Parameters
Gel area: 8.3×7.3cm
Gel thickness: 0.75, 1.0, 1.5mm (optional)
Option tooth number of sample comb: 10, 15
Glass size: short glass plate (10.1×7.3cm) ; long glass
plate (10.1×8.2cm)
set
pc
set
pc
pc
pc
pc
pc
pc
pc
pc
1
1
1
5
5
2
2
2
2
1
1
Lid (power supply)
Bottom tank
Electrode core
Gel glass thick plate
Gel Glass thin plate
10-well comb
15-well comb
Gel casing stand
Casing frame
Baffle
Gel Releaser
Name Unit Quantity
