Standard configuration
Technical Parameters
Gel size: (W×L) : 60×75mm
Sample comb: 1.0/1.5mm 6/11wells
Buffer volume: 300
Suitable for rapid separation,
identification, preparation of DNA, and
determination of its molecular weight
Polycarbonate injection molding, no
leakage
The heat dissipation hole design on the
upper cover effectively prevents
condensation of water vapor
Dedicated telescopic elastic glue
maker, ensuring cleanliness and no
glue leakage
Limit function, effectively preventing
reverse installation of positive and
negative electrodes
Detachable electrodes for easy
replacement and maintenance
99.99% high-purity platinum electrode,
the best conductivity, anti-aging
Features
•
•
•
•
•
•
•
DL-SUB01
Horizontal Electrophoresis Tank
Lid with cables
Body tank with electrodes
Gel box
Gel tray
1.0mm thickness 6 wells comb
1.0mm thickness 11 wells comb
1.5mm thickness 6 wells comb
set
set
pc
pc
pc
pc
pc
1
1
1
1
2
2
2
Name Unit Quantity
D
lectrophoresis
E
