Standard configuration
Technical Parameters
Gel area:
Large gel: 120×120 mm;
Wide gel: 120×60 mm;
Long gel: 60×120 mm;
Small gel: 60×60 mm.
Number of sample combs: 2, 3, 6, 8, 11, 13, 18, 25.
Buffer volume: 700.
Suitable for rapid separation,
identification, preparation of DAN, and
determination of its molecular weight
Polycarbonate injection molding, no
leakage
Four different sizes of gels can be
made, and two types of gel makers are
optional
Limit function to prevent reverse
installation of positive and negative
electrodes
Detachable electrodes for easy
replacement and maintenance
99.99% high-purity platinum electrode,
the best conductivity, anti-aging
The large glue and the small glue box
are designed as one front and back, the
big glue can hold up to four rows of
combs at a time
Fluorescent ruler on the bottom of the
tray
Features
•
•
•
•
•
•
•
•
DL-SUB02
Multi-functional Horizontal Electrophoresis Tank
Lid with cables
Body tank with electrodes
Gel box
Large gel tray（120Ｘ120）
Wide gel tray（120Ｘ60）
Long gel tray（60Ｘ120）
Small gel tray（60Ｘ60）
Sample comb: 2+3 well
Sample comb: 6+13 well
Sample comb: 8+18 well
Sample comb: 15+25 well
set
set
piece
piece
piece
piece
piece
piece
piece
piece
piece
1
1
1
1
1
1
2
1
1
1
4
Name Unit Quantity
D
lectrophoresis
E
