Standard configuration
Technical Parameters
Gel size (WＸL): 130Ｘ200mm、130Ｘ150mm
Sample comb: 1.0mm 14、18、26 wells
1.5mm 18-well
Buffer volume: 800
Suitable for nucleic acid
electrophoresis, separation and
identification of DNA and
determination of its molecular weight
Polycarbonate high-strength
transparent plastic injection molding,
no leakage, impact resistance
Professional shielding blue light
clamshell design, open the cover can
effectively dissipate heat
The bottom level adjustment knob can
adjust the level of the electrophoresis
tank
Two different gel sizes, meet the needs
of general and high-throughput
electrophoresis
The front and back design of the gel
box, can save space
The background strip at the bottom of
the tray is more conducive to observing
sample loading
99.99% high-purity platinum electrode,
the best conductivity
Features
•
•
•
•
•
•
•
•
DL-SUB03
Multi-functional Horizontal Electrophoresis Tank
Lid with cables
Body tank with electrodes
Gel box
Large gel tray（130Ｘ200）
Small gel tray（130Ｘ150）
1.0mm thickness 14 wells comb
1.0mm thickness 18 wells comb
1.0mm thickness 26 wells comb
1.5mm thickness 18 wells comb
set
set
pc
pc
pc
pc
pc
pc
pc
1
1
1
1
1
2
2
2
2
Name Unit Quantity
D
lectrophoresis
E
