Technical Parameters
Transfer area: 110×90mm
Used together with DL-MINI01, 04
Equipped with a special bubble roller for easy
removal of bubbles
Effective transfer gel area: 110×90mm
Lid with cables
Bottom tank
Transfer core
Gel Holder Cassette
Ice cooling unit
Blue cooling unit
Transfer Sponge Pad
Set
pc
Set
pc
pc
pc
pc
1
1
1
2
1
2
4
DL-ZY02
Transfer electrophoresis tank
This product is suitable for fast and
high-quality transfer of small protein
gels
The tank body is made of highly
transparent polycarbonate material,
which is one-time injection molding, no
leakage and impact resistance
Positive electrodes are separated by
4cm to generate a strong electric field
for efficient protein transfer
99.99% high-purity platinum electrode,
better conductivity, corrosion
resistance and aging
Multiple security designs to avoid
security issues caused by improper
operation
Built-in ice box or Blue cooling unit is
optional to quickly absorb the heat
generated during electrophoresis
Special open Gel Holder Cassette, easy
to operate
Can transfer two 83*73mm gels at the
same time
Features
•
•
•
•
•
•
•
•
Standard configuration
Name Unit Quantity
D
lectrophoresis
E
