D1524R
High-speed Refrigerated
Micro Centrifuge
Electronic Magnetic door locking system - the lid
can be closed with one hand soft touch
Precooling, the compressor automatically starts
cooling as long as the set temperature is lower than
the ambient temperature
Sound indicator at the end of running.
Temperature range -20℃ to 40℃
Short pre-cooling time of only 7minutes from room
temperature to 4℃
Up to 9 program storage capacity
3-layer sealed rotors ensure safe centifugation
High-strength aluminum alloy rotor can be fully
autoclavable at 121℃
Rotor imbalance detection alarm
Adjustable acceleration/deceleration at 9 levels
allows gentle braking at low speed for better
separation
Five rotors with 0.2
, 0.5
, 1.5
, 2
and 5
centrifuge tubes/ PCR tubes capacity
An external condensation tank prevents water
accumulation within centrifuge chamber
Ideal for centrifugation of temperature
sensitive samples, such as live cells, animals or
proteins. It allows them to be used in a
multitude of applications, including pelleting
of DNA and RNA samples, pelleting of PCR
amplified nucleic acids, separation of antibody
and protein precipitates, performing enzymatic
tests, removing cell debris from cell
homogenates, and achieving bacterial and
yeast cell fractionation.
Features
•
•
•
•
•
•
•
•
•
•
•
•
Applications
Specifications D1524R
Max. RCF
Temperature setting
Run Time
Acceleration and deceleration time
Motor Type
Noise Level
Dimensions[WxDxH]
Weight
21,380×g, step: 10×g
-20℃- 40℃
30s-99 min; HOLD (continuous running)
25s↑25s↓
Brushless DC motor
≤56dB
332 × 553 × 283mm
30kg
15,000rpm (200-15,000rpm)
in 100rpm increments.
36×0.2/0.5，24×1.5/2，
4×0.2 PCR 8-tube strip，
12×5(cone bottom)，
18×5(round bottom)
Dual door lock, over-speed detection,
over-temperature detection
with Internal diagnosis system.
Single-phase，100-120V/200-240V,
50Hz/60Hz.500W
Rotation speed/RCF switchover,
inching operation, running
processindicator,
sound alert.
Adjustable acceleration/deceleration
at 9 levels program storage capacity.
Max. Speed
Capacity
Safety Performance
Power Requirements
Other functions
Clear LCD
large display
Ergonormic electronic
door lock design
Intuitive operation
control panel
