DM0306
Low Speed centrifuge
Beautiful appearance and small space occupation;
Speed: 3400 rpm (1600xg);
Rotor capacity: supports 6 × 3-10 blood collection tubes;
Electronic timer with a time setting range of 0.5-30 minutes,
capable of continuous operation;
LED screen, capable of displaying remaining running time;
1st gear up speed, 3rd gear down speed, supports gentle
braking function, meets different experimental needs;
Automatic lock cover, when the centrifuge is running, the
upper cover cannot be opened, and the mechanical door lock
is firmly secured to prevent debris from escaping;
Transparent cover, convenient for sample observation and
optical calibration, providing maximum safety and durability;
DM0306 is widely used in clinical practice and is an ideal choice for serum and plasma sample separation in
biochemical and medical laboratories. It is the main instrument for sample pretreatment in clinical laboratories,
blood banks, medical schools, and medical research institutions.
•
•
•
•
•
•
•
•
Features
Applications
Specifications DM0306
3400rpm
1600×g
6×3-10 Blood collection tube
＜10S
＜20S
LED
0.5-30min/Hold
1↑/3↓
AC fixed frequency brushless motor
IP20
≤63dB
100-120V，200-240V
50Hz，60Hz
80W
4A Replaceable
359×318×222mm
5.3kg
5-40℃，80% RH
Explosion proof test, door lock protection,manual door lock can be unlocked
Maximum speed
Maximum relative centrifugal force
Rotor capacity
Maximum acceleration time
Maximum deceleration time
Timer display
Time setting range
Speed up/down gear
Motor type
Shell protection level
Noise level
Voltage
frequency
power
Protection circuit breaker
Size [length x width x height]
Weight [kg]
Allow ambient temperature and humidity
Security performance
Maximum capacity：6×10
Maximum speed：3400rpm
Maximum centrifugal force：
1600×g
Texture of material：
High strength plastic
SE6-10P Cat. No.19400145
