DM0506
Low-speed Centrifuge
Speed range from 300-5000 rpm
Set and displayed by RPM or G-force
Two programs P1/P2, easy to start the
procedure by one key
Two deceleration speeds setting to meet
different requirements
Easy-to-read LCD display and sound alert
Automatic lid-lock release after running
Maintenance-free brushless DC motor
Features
•
•
•
•
•
•
•
DM0506 is widely used in the medical industry.
Ideal for separation of serum, plasma, urine,
fecal samples in biochemical & medical
laboratories. It is an essential equipment of
every clinical laboratory, blood bank, medical
college and medical research institute.
Applications
Specifications
DM0506
Speed Range
Max. RCF
Speed accuracy
Rotor type
Display
Preloaded Program
Acceleration/Deceleration
Dimension[WxDxH]
Weight
300-5000rpm, increment:10rpm
2600×g，increment：10×g
±20rpm
6×1.5-5/7/10/154×20/50
LCD
P1/P2
1↑ 2↓
300X240X180mm
5.2kg
30sec-99min, HD
(continuous running)
Door interlock, Overspeed detector,
Automatic internal diagnosis
Single-phase, 100V-240V,
50Hz/60Hz, 70W
Speed/RCF switch;
sound-alert function
Run Time
Safety Devices
Motor Brushless DC motor
Power Requirements
Advanced features
5 adapter, Adapted to 13×75mm
blood collection tube
Applied to: A6-15P
A5P17 Cat. No.19500022
1.5/2mL adapter, Adapted to 11×43mm
centrifuge tubes and cryogenic vials.
Applied to: A6-15P
A2P17 Cat. No.19500023
Available adapters
entrifuges
C
FeaturesFeatures
DM0506
Max. speed: 5000rpm
Max. RCF:2600×g
Rotor capacity: 6×15mL
Rotor material: High strength plastic
A6-15P Cat. No.19400295
DM0506
Max. speed: 5000rpm
Max. RCF: 2600×g
Rotor capacity: 4×50mL
Rotor material: High strength plastic
A4-50P Cat. No.19400294
Available rotors
Rotor material: High strength plasticRotor material: High strength plastic
Cat. No.19400294Cat. No.19400294
