D1524C
Hematocrit Centrifuge
D1524
High-speed Micro Centrifuge
Speed range of 200‒15000 rpm to meet various
experimental needs.
Motor lock adsorption design allows one-handed
lid closure.
Intuitive menu and LCD display for easy and clear
operation.
Maintenance-free brushless DC motor ensures stable and reliable performance.
Stores up to 9 frequently used programs for quick recall.
Nine acceleration/deceleration rates with soft braking for smoother separation.
Supports speed/RCF conversion, short spin, and audible alarm functions.
Dual-lock lid, overspeed, over-temperature, and diagnostic systems for enhanced safety.
Features
•
•
•
•
•
•
•
•
entrifuges
C
Specifications
D1524
Max. RCF
Run Time
Acceleration and deceleration time
Motor Type
Noise Level
Dimensions[WxDxH]
Weight
21,380×g, step: 10×g
30s-99 min; HOLD (continuous running)
25s↑25s↓
Brushless DC motor
≤64dB
280 × 400 × 240mm
8.8kg
15,000rpm (200-15,000rpm)
in 100rpm increments.
24×1.5/2，
36×0.5,
4×PCR-8 strips,
12×5,18×5
Dual door lock, over-speed detection,
over-temperature detection
with Internal diagnosis system.
Single-phase，200-240V，50/60Hz，210W
100-120V，50/60Hz，200W
Rotation speed/RCF switchover,
inching operation, running
processindicator,
sound alert.
Adjustable acceleration/deceleration
at 9 levels program storage capacity.
D1524C
13,680×g,step: 10×g
30s-99min；HOLD(continuous running)
25s↑25s↓
Brushless DC motor
≤65dB
280×400×240mm
8.8kg
12,000rpm (200-12,000rpm)
in 100rpm increments.
AC24P(Capillary tubes×24)
Dual door lock, over-speed detection,
over-temperature detection
with Internal diagnosis system.
Single-phase，200-240V，50Hz/60Hz，210W
100-120V，50Hz/60Hz，200W
Rotation speed/RCF switchover,
inching operation, running
processindicator,
sound alert.
Adjustable acceleration/deceleration
at 9 levels program storage capacity.
Max. Speed
Capacity
Safety Performance
Power Requirements
Other functions
The high-speed centrifuge is widely used in molecular biology, clinical chemistry, microbiology, as well as
clinical diagnostics and scientific research fields.
The hematocrit centrifuge measures red blood cell volume and separates micro samples. It supports
biochemical, immunological, genetic, and clinical tests, bilirubin measurement in neonatal samples, and
DNA/RNA extraction. Widely used in clinical and veterinary applications.
Applications
entrifuges
C
