D3024

High Speed Micro Centrifuge

Double cooling air design ensures fast cooling of the

rotor and low energy consumption

3-layer sealed rotors ensure safe centifugation

Brushless motor drive, maintenance free

Safety features include door interlock; excessive speed

and temperature detection; automatic self-diagnostics

Outstanding aluminum alloy rotors fully autoclavable at

121℃ temperature and high pressure disinfection

Five rotors are optional complete with 24 places

1.5/2.0 tubes,5.0, 0.2 and 0.5 tubes with

adapters

Suitable for numerous biological, chemistry, clinical and

research applications including molecular biology,

clinical chemistry labs, wide variety of microbiology

applications, such as DNA, RNA or protein isolation and

many more.

Features

Applications

•

Eﬀective Ventilation System Conventional design

Brushless DC motor

Wide range of rotors

Limited ventilation on the upper

side of the rotor

Double cooling air design, enforcing air

cooling from both the upper and lower

side for the rotor.

entrifuges

󾋸󾋽󾋼

Fully autoclavable

Three-layer seal

Mechanical safety

Speciﬁcations D3024

Max. RCF

Speed Accuracy

Run Time

Acceleration/Braking time [Sec]

Motor

Noise Level

Dimension[W×D×H]

Weight

21380×g, increment:10×g

±20 rpm

30sec-99min/Continuous

25s↑25s↓

Brushless DC motor

≦64dB

280×364×266mm

12kg

15000rpm(200-15000rpm),

increment:10rpm

Dual door interlock,

Over-speed detection,

Automatic internal diagnosis

Single-phase, AC200V-400V,

50Hz/60Hz, 5A,AC100V-120V,

50Hz/60Hz, 8A 200W

Speed/RCF switch;

Short-time run function;

sound-alert function

Max. Speed

Rotor Capacity

Safety Devices

Power Requirements

Other functions

DLAB rotors are manufactured from military-industrialgrade

aluminum alloy with high mechanical strength for precise

running and safety (excludes D2012 plus rotor)

High strength aluminum alloy rotors are fully

autoclavable, withstanding steam sterilizing at

121°C for 20 minutes

D3024&D1524&D1524Rrotors are designed to

prevent sample leakage. Each and every rotor is

hermetically sealed by three rubber seals.

DLAB centrifuges conﬁrm to MCA standard

IEC/EN61010-2-20, causing disruption by partially

cutting and overloading rotor assembly, and

guarantees that no part shall be detached to cause

danger to person or the environment.

Every rotor can reach a maximum Speed of 15000rpm

Rotors are seated on a tapered shaft,concentric and

self-aligning, perfect to achieve running stability at high

speeds

D3024&D1524&D1524R with three-layer sealed rotors/

anti- sample overﬂow prevents accidental leakage

D3024&D1524&D1524Rrotors have passed MCA test

according to IEC/EN61010-2-20, including mechanical

safety and bio-safety tests

Powerful cooling system minimizes rotor heating.

D3024&D1524 rotors maintain at 10°C and D1524R rotors

less than 8°C after running an hour

Rotor Features

Seals within the

aluminum alloy rotor

•

Three rubber seals ﬁtted to

achieve bio-safe condition

36×0.2/0.5,24×1.5/2,

4×0.2 PCR 8-tube strip,

12×5(cone bottom),

18×5(round bottom)

entrifuges

󾋸󾋽󾋽

for D3024&D1524&D1524R

Max. speed: 15000rpm

Max. RCF: 21380×g

Rotor capacity: 24×0.2/0.5/1.5/2

Rotor material: Aluminum alloy

Biosealing: Yes

Available rotor adapters: A02P2,A05P2

AS24-2 Cat. No.19400069

0.2 rotor adapter

Used with A12-2, A12-2P, AS24-2 and

A24-2P rotors 24pcs/pk

A02P2 Cat. No.19500001

0.5 rotor adapter

Used with A12-2, A12-2P, AS24-2

and A24-2P rotors

24pcs/pk

A05P2 Cat. No.19500002

for D3024&D1524&D1524R

Max. speed: 15000rpm

Max. RCF: 21380×g

Rotor capacity: 36×0.2/0.5

Rotor material: Aluminum alloy

Biosealing: Yes

Available rotor adapters: A02P05

AS36-05 Cat. No.19400071

for D3024&D1524&D1524R

Max. speed: 15000rpm

Max. RCF: 21380×g

Rotor capacity:

32×0.2 or 4×0.2 PCR 8-tube strip

Rotor material: Aluminum alloy

Biosealing: Yes

AS4-PCR8 Cat. No.19400072

for D3024&D1524&D1524R

Max. speed: 15000rpm

Max. RCF: 21380×g

Rotor capacity: 12×5(cone bottom)

Rotor material: Aluminum alloy

Biosealing: Yes

AS12-5V

Cat. No.19400070

Available rotors

Available adapters

(cone bottom)

for D3024&D1524&D1524R

Max. speed :15000rpm

Max. RCF:21380×g

Rotor capacity:

18×5(round bottom)

Rotor material:Aluminum alloy

Biosealing:Yes

AS18-5

Cat. No.19400073

(round bottom)

0.2 rotor adapter

Used with AS36-05 rotor

36pcs/pk

A02P05 Cat. No.19500003
