DM1424
Hematocrit Centrifuge
DM1224
Economical Hematocrit Centrifuge
Speed range of 200-12000 rpm Precise and independent
control of speed and time
Easy operation with intuitive menu and LCD display
Maintenance-free brushless DC motor
Pulse operation for fast and convenient quick spins
Advance features include speed/RCF switch; short-time
run function; audible alert function
Safety features include door interlock, overspeed
detector;over-temperature detector; automatic internal
diagnosis and automatic rotor identification
Features
•
•
•
•
•
•
Speed range of 500-12000 rpm
Precise control of speed and time
Maintenance-free brushless DC motors
Door interlock
DLAB hematocrit centrifuges are used for determination of
erythrocyte fractions in blood as well as micro solution
separations. It provides hematocrit values (HCT) for testing
in biochemistry, immunity, genetics, blood separation and
for general clinical tests for diagnostic purposes and also
for dope tests. They have special applications for the
photometric determination of bilirubin content in neonate
blood samples. They are suitable for extraction of DNA and
RNA. Veterinary clinics and Vitamins testing for Infants.
Features
Applications
•
•
•
•
entrifuges
C
Specifications DM1424 DM1224
Max. RCF
Speed Accuracy
Run Time
Motor
Display
Acceleration/Braking time
Dimension[WxDxH]
Weight
13680×g
±20
30sec-99min/Continuous
Brushless DC motor
LCD
30s↑30s↓
280×364×274mm
10.5kg
13680×g
±100
10sec-99min/Continuous
Brushless DC motor
LCD
40s↑40s↓
280×364×213mm
8.5Kg
DM1424 & DM1224
Max. speed: 12000rpm
Max. RCF: 13680×g
Rotor capacity: 24×capillary tubes
Rotor material: High strength aluminum
AC24 Cat. No.19400047
200-12000rpm,
increment: 10rpm
Door interlock,Overspeed detector;
Automatic internal diagnosis,
Automatic rotor identification
Single-phase,
200V-240V,50Hz/60Hz,
5A; 100V-120V,50Hz/60Hz, 5A
160W
Speed/RCF switch;
Short-time run function;
sound-alert function
Speed/RCF switch;
Short-time run function;
sound-alert function
Speed Range
Safety Devices
Power Requirements
Advanced features
500-12000rpm,
increment: 100rpm
Door interlock
Single-phase,
200V-240V,50Hz/60Hz, 5A;
380W
Available rotors
