MX-S+
Digital Vortex Mixer
LCD screen displays real-time speed and time for
easy adjustment and monitoring.
Adjustable speed ranges from gentle to vigorous
mixing to suit various needs.
Stable with pressure-mounted accessories to
prevent slippage and splashing.
Brushless DC motor for high stability and
maintenance-free operation.
Sturdy base ensures stability during operation for
safety.
Includes various accessories for different sizes and
types of tubes and plates.
Low noise for a quiet working environment.
•
•
•
•
•
•
•
Speed
Display
Amplitude
Operating Modes
Time Range
Motor Type
Dimensions (L×W×H)
Weight
Power Supply
Input Voltage
Power Consumption
100-3000 rpm
LCD
4 mm
Touch, Continuous
1 s - 99 min 59 s
Brushless DC Motor
160x146x115mm
3.4kg
100-240 V, 50/60 Hz
24 V
25 W
MX-S+
Features
Specifications
Ambient
Temperature & Humidity
5-40°C, 80% RH
IP21
Enclosure Protection
ixing
M
VT2.4
Ampule/Tube
Attachment
VT2.7.4-VT2.7.6
Horizontal
Plastic Clamp
Accessories of Vortex Mixer MX-S+ & MX-Pro
VT2.6 Snap-in Universal
top plate,Ø85mm
VT2.3 Universal top
plate,Ø100mm
PS2.1 & PS2.2Microplate clampVT2.5 Erlenmeyer flask
attachment(100mL-250m
VT2.5 Erlenmeyer flaskVT2.5 Erlenmeyer flaskVT2.5 Erlenmeyer flask
PS2.1 & PS2.2Microplate clampPS2.1 & PS2.2Microplate clampPS2.1 & PS2.2Microplate clamp
VT2.4VT2.4VT2.4
ixing
M
Universal top plate，compatible
with VT1.3.1-VT1.3.12 Tube Adapter
VT2.3 Cat. No.18901365
Ampule/Tube Attachment，4pc
ampule/tube（0.2-15）
VT2.4 Cat. No.18901366
Top cup，Suitable for MX-Pro
VT2.1 Cat. No.18901379
Top cup，Suitable for MX-S+
VT2.1 Cat. No.18901380
Flat Rubber Sleeve (Standard)
VT2.2 Cat. No.18901373
Snap-in Universal top plate，
compatible withVT2.6.1-VT2.6.5
Tube Adapter
VT2.6 Cat. No.18901368
Tube Adapter，25 holes ×1
Test Tube
VT2.6.1 Cat. No.18901378
Tube Adapter，21 holes ×2
Test Tube
VT2.6.2 Cat. No.18901377
Tube Adapter，16 holes ×5
Test Tube
VT2.6.3 Cat. No.18901376
Tube Adapter，8 holes ×15
Test Tube
VT2.6.4 Cat. No.18901375
Tube Adapter，4 holes×50
Test Tube
VT2.6.5 Cat. No.18901374
Horizontal Plastic Clamp，
24 holes×1.5 Test Tube
(Circular plate)
VT 2.7.4 Cat. No.18901870
Horizontal Plastic Clamp，
12 holes×15 Test Tube
(Circular plate)
VT 2.7.5 Cat. No.18901871
Horizontal Plastic Clamp，
6 holes×50 Test Tube
(Circular plate)
VT 2.7.6 Cat. No.18901872
Erlenmeyer flask attachment
(100-250)，Operating speed:
0~1500rpm
VT2.5 Cat. No.18901367
Microplate clamp，Suitable for workboards
(full skirt PCR plates, cell culture plates,
enzyme-linked immunosorbent assay
plates, deep well plates, etc. Half skirt/no
skirt PCR plates need to be used with
rectangular foam, which is already included)
PS2.1 Cat. No.18901360
Snap-in Microplate clamp,Suitable for
workboards (full skirt PCR plates, cell culture
plates, enzyme-linked immunosorbent assay
plates, deep well plates, etc. Half skirt/no
skirt PCR plates need to be used with
rectangular foam, which is already included)
PS2.2 Cat. No.18901361
Accessories of MX-S+&MX-Pro
Accessories of MX-S+&MX-Pro （New）
*Material color may vary slightly during the initial launch phase. Please refer to the actual product.
