MX-Pro
Infrared Digital Vortex Mixer
The Infrared Digital Vortex Mixer provides an efficient and
precise mixing solution for your laboratory!
LCD screen displays real-time speed and time
for easy adjustment and monitoring.
Adjustable speed ranges from gentle to
vigorous mixing to suit various needs.
Dual-sided IR sensing for automatic tube
detection and mixing, accommodating different
user preferences.
Stable with pressure-mounted accessories to
prevent slippage and splashing.
Brushless DC motor for high stability and
maintenance-free operation.
Sturdy base ensures stability during operation
for safety.
Includes various accessories for different sizes
and types of tubes and plates.
Low noise for a quiet working environment.
Molecular Biology
Chemical Analysis
Pharmaceutical Research
Biotechnology
Clinical Laboratories
With advanced design concepts and manufacturing
technology, the device features a sleek, streamlined, and
aesthetically pleasing appearance. The digital interface
provides real-time speed and time display, allowing
users to easily set and monitor mixing parameters. Its
stable vortex motion ensures uniform sample mixing,
making it ideal for molecular biology, chemical analysis,
and other scientific research fields.
MX-Pro
Speed
Display
Amplitude
Operating Modes
Time Range
Motor Type
Dimensions (L×W×H)
Weight
Power Supply
Input Voltage
Power Consumption
•
•
•
•
•
•
•
•
•
•
•
•
•
Features
Specifications
Applications
Ambient
Temperature & Humidity
100-3000 rpm
LCD
4.5 mm
IR, Continuous
1 s - 99 min 59 s
Brushless DC Motor
160 × 145 × 145 mm
3.9 kg
100-240 V, 50/60 Hz
24 V
30 W
5-40°C, 80% RH
IP21
Enclosure Protection
The Infrared Digital Vortex Mixer provides an efficient and The Infrared Digital Vortex Mixer provides an efficient and
ixing
M
VT2.4
Ampule/Tube
Attachment
VT2.7.4-VT2.7.6
Horizontal
Plastic Clamp
Accessories of Vortex Mixer MX-S+ & MX-Pro
VT2.6 Snap-in Universal
top plate,Ø85mm
VT2.3 Universal top
plate,Ø100mm
PS2.1 & PS2.2Microplate clampVT2.5 Erlenmeyer flask
attachment(100mL-250m
VT2.5 Erlenmeyer flaskVT2.5 Erlenmeyer flask
PS2.1 & PS2.2Microplate clampPS2.1 & PS2.2Microplate clamp
VT2.4VT2.4
ixing
M
Universal top plate，compatible
with VT1.3.1-VT1.3.12 Tube Adapter
VT2.3 Cat. No.18901365
Ampule/Tube Attachment，4pc
ampule/tube（0.2-15）
VT2.4 Cat. No.18901366
Top cup，Suitable for MX-Pro
VT2.1 Cat. No.18901379
Top cup，Suitable for MX-S+
VT2.1 Cat. No.18901380
Flat Rubber Sleeve (Standard)
VT2.2 Cat. No.18901373
Snap-in Universal top plate，
compatible withVT2.6.1-VT2.6.5
Tube Adapter
VT2.6 Cat. No.18901368
Tube Adapter，25 holes ×1
Test Tube
VT2.6.1 Cat. No.18901378
Tube Adapter，21 holes ×2
Test Tube
VT2.6.2 Cat. No.18901377
Tube Adapter，16 holes ×5
Test Tube
VT2.6.3 Cat. No.18901376
Tube Adapter，8 holes ×15
Test Tube
VT2.6.4 Cat. No.18901375
Tube Adapter，4 holes×50
Test Tube
VT2.6.5 Cat. No.18901374
Horizontal Plastic Clamp，
24 holes×1.5 Test Tube
(Circular plate)
VT 2.7.4 Cat. No.18901870
Horizontal Plastic Clamp，
12 holes×15 Test Tube
(Circular plate)
VT 2.7.5 Cat. No.18901871
Horizontal Plastic Clamp，
6 holes×50 Test Tube
(Circular plate)
VT 2.7.6 Cat. No.18901872
Erlenmeyer flask attachment
(100-250)，Operating speed:
0~1500rpm
VT2.5 Cat. No.18901367
Microplate clamp，Suitable for workboards
(full skirt PCR plates, cell culture plates,
enzyme-linked immunosorbent assay
plates, deep well plates, etc. Half skirt/no
skirt PCR plates need to be used with
rectangular foam, which is already included)
PS2.1 Cat. No.18901360
Snap-in Microplate clamp,Suitable for
workboards (full skirt PCR plates, cell culture
plates, enzyme-linked immunosorbent assay
plates, deep well plates, etc. Half skirt/no
skirt PCR plates need to be used with
rectangular foam, which is already included)
PS2.2 Cat. No.18901361
Accessories of MX-S+&MX-Pro
Accessories of MX-S+&MX-Pro （New）
*Material color may vary slightly during the initial launch phase. Please refer to the actual product.
Cat. No.18901870Cat. No.18901870
Cat. No.18901871Cat. No.18901871
Cat. No.18901872Cat. No.18901872
ixing
