iquid Handling
L
EcoVac
Economical Vacuum Aspirator
Small，compact and easy to use system for the convenient
handling of liquid waste disposal.
Features
Specifications
Small and compact to fit in the cabinet,
on the benchtop or even beneath the
bench
Easy to switch between manual
aspiration and continuous aspiration
mode, reducing RSI (Repetitive Strain
Injury) and improving efficiency
Collection bottle outlet with
hydrophobic filter prevents aerosol and
liquid contamination
Brushless motor offers low noise and
long life
Different adapters are available to fit a
multitude of laboratory supplies
The parts in contact with liquids can be
autoclaved
Adjustable vacuum level with indicator
light is designed for various applications
Vacuum range
Max. Flow
Max. aspiration speed
Motor type
Input voltage
Dimension [W×D×H]
Weight
Brushless Motor
100-220VAC, 50/60Hz
180×240×340 mm
2.8kg
0-500mbar
15L/min(air)
17/s(Liquid)
----------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------
---------------------------------------------------------------------------------------------------------------------
---------------------------------------------------------------------------------------------------------------------
---------------------------------------------------------------------------------------------------------------------
---------------------------------------------------------------------------------------------------------------------
---------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------
---------------------------------------------------------------------------------------------------------------------
---------------------------------------------------------------------------------------------------------------------
---------------------------------------------------------------------------------------------------------------------
---------------------------------------------------------------------------------------------------------------------
---------------------------------------------------------------------------------------------------------------------
Bottle
2L standard,
1L optional with adaptor
Hanging
handles
on both
sides
Vacuum level indicator light
Easy to switch between manual aspiration and
two-level adjustable continuous aspiration:
Level 1: Standard continuous aspiration mode.
Level 2: Fast continuous aspiration mode
enhanced
•
•
•
•
•
•
•
iquid Handling
L
A
B
C
D
E
F
G
H
I
J
K
----------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------
Wide range of applications
• Aspiration of eluent
• Removal of supernatants during nucleic acid extraction
• Removal of culture media
• Removal of wash solutions from immuno-assay well-plate
• Removal of buffers of Western blot strips
• Removal of excess liquid from slides and Petri dishes
• Aspiration of supernatants after centrifugation
8 channel needle Ø1.5mm
Single needle Ø1.5mm, 40mm
Single needle Ø1.5mm, 120mm
tip detrusion adapter 1 tip
1L bottle fitting
1L collection bottle
Handle Hoop (Vacuum Aspirator)
8-channel tip detrusion adapter 200 tip
Single needle Ø2.5mm, 40mm
Single needle Ø2.5mm, 120mm
tip detrusion adapter 200 tip
EcoVac is suitable for any application where the single liquid suction volume is less than 2L.The applicability
includes use of various common consumables,which can be widely used in the collection and removal of liquids
in experiments of microorganisms,molecules,proteins,cells,etc.,and other applications such as RNA/DNA
extraction,Western blots and ELISA.
