Compact, user-friendly design
Level detection system prevents bottle
overfill
Control knob for vacuum setting
The parts in contact with liquids are
autoclavable
Easy to disassemble and clean
Ideal tool to avoid lab air
contamination and protect personnel
safety
Adjustable vacuum level with indicator
lig
ht is designed for various
applications
For laboratory waste recovery and
separation of liquid and solid.
It can be widely used in cell culture, DNA
extraction, microplate waste removal,
and any other liquid separation or
recovery.
Best replacement for the common
vacuum pump, for all kinds of waste
liquid recovery, especially biological,
chemical and radioactive liquids.
Self-closing connectors to
avoid escape of drops or
aerosols from disconnected bottle
Stand for transferring the
bottle securely
and holding
the hand operator
Features
Applications
Sensitive level sensor to
prevent liquid overflow
SafeVac
Vacuum-Controlled Aspiration System
Safe and efficient system for labs handling critical or biological
liquid waste.
•
•
•
•
•
•
•
vacuum level
indicator light
iquid Handling
L
Wide range of adapters to fit well with different tubes, microplate and disk plate, all of which can be fully
autoclaved (At 121℃ 1 bar for 20 minutes. After autoclaving the equipment must be cooled down before use).
Vacuum range
Max. Flow
Max. aspiration speed
Bottle
Autoclave component
Noise Level
Input voltage
Dimension[WxDxH]
Weight
0-600mbar
15L/min（air）
17/s ( Liquid )
4L
Tube;waste bottle;operation handle;
≤55dB
100-240VAC，50/60
Hz
180x240x450mm
3kg
----------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------
A
B
C
D
E
F
G
H
I
J
8-channel tip detrusion adapter 200 tip
8 channel needle Ø1.5mm
Single needle Ø2.5mm, 40mm
Single needle Ø2.5mm, 120mm
Single needle Ø1.5mm, 40mm
Single needle Ø1.5mm, 120mm
tip detrusion adapter 200 tip
tip detrusion adapter 1 tip
SafeVac Handle bracket
Handle Hoop (Vacuum Aspirator)
----------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------
Specifications
iquid Handling
L
