Compact and portable, small foot print

Suitable for any bench top space including

laminar ﬂow cabinet. the collection bottle is

independent of the vacuum source and power

supply, and can be placed at any position.

The 1L bench-top compact vacuum aspirator with

replaceable battery is designed for ﬂexible handling of small

amounts of liquids, with one key control, easy operation

and wide application.

One-key start to work with built-in

rechargeable battery independent of

exterior power supply

Continuous work for 5 hrs after fully charged.

Fast, safe and reliable

Aspiration speed up to 1. 6 L/min;

hydrophobic ﬁlters against contamination.

Dual function of aspiration and ﬁltration

1L collection bottle in standard package,

with 500



collection bottle (autoclavable) and

ﬁltration ﬂask optional.

• Removal of supernatant from pellets;

· Removal of culture media；

· Quick removal of spillage from the bench top；

· Vacuum Filtration

Smart VAC

Bench top compact vacuum

aspirator

•

Specifications

- - --- -- --- --- ---- - --- ---- - --- ------ - - ------ --- - ---- --- - ---- --- --- -- --- --- -- --- --- ---- - --- ------ - - -------- --- --- ------ -

- - --- -- --- --- ---- - --- ---- - --- ------ - - ------ --- - ---- --- - ---- --- --- -- --

- --

- - - ------ --- - ---- --- --- -- ----- --- ------ --- --- -

- - --- -- --- --- ---- - --- ---- - --- ------ - - ------ --- - ---- --- - ---- --- --- -- --- --- -- --- --- ---- - --- ------ - - -------- --- --- ------ -

Vacuum Range

Aspiration speed

Motor type

Power

Battery

Noise Level

Dimension [WxDxH]

Weigh

0-600mbar

1.6 L/min(air)

Brushless DC motor/ Brush motor

DC 12V ，1.0A

Rechargeable lithium battery 2000mA/h

53dB

127 x 144 x 244mm

0.5kg

Adapter

Bottle

1 tip detrusion adapter,

8-channel tip detrusion adapter

Features

1L collection bottle

in Standard package,

500 bottle with an adaptor,

or ﬁltration ﬂask optional

iquid Handling

󾋼󾋹
