StepMate
Stepper
Positive-displacement, continuously adjustable, repetitive dispenser
Volume selection dial
Optimized for smooth dispensing of
even the smallest volumes
Slide upwards to fill
the dispenser tip
Stop lever to secure
the dispenser tip
Dispenser tip Nominal Volume
Dispensing Volume per Step
Features
Applications
How to select dispensing volume
Slim, light and robust
Wide dispensing volume from 10 to 5
Up to 48 dispensing steps in succession
Equipped with durable dispenser tip stop
lever
Fits different sizes of disposable
polypropylene dispenser tips from 0.5
to 50
Ideal for any application requiring
repetitive dispensing in the clinical,
biological, chemical, food and beverage,
pharmaceutical industry.
Find the required dispensing volume in the
table.
Use the volume selection dial to set the
required volume.
Select and insert a suitable dispenser tip.
Follow the maximum dispensing steps as
stated.
10
25
50
100
250
500
1000
20
50
100
200
500
1000
2000
30
75
150
300
750
1500
3000
40
100
200
400
1000
2000
4000
50
125
250
500
1250
2500
5000
0.5

1.25

2.50

5.00

12.50

25.00

50.00

Steps
Sel.
Tips
48
1 2 3 4 5
23 15 11 8
iquid Handling
L
󾋺󾋻
iquid Handling
L
󾋺󾋼
DLAB dispenser tips are convenient for viscous or foaming solutions, volatile
liquids and applications where repetitive dispensing of volumes in long series is
required
The dispenser tips are made from high quality materials without soft lubricants
or other additives.
Note: The first and last dispensing liquid should be discarded for precision.
Cat. No.
Number of steps
Dial setting
dispenser tip
volume
Dispensing volume per step
Systematic
Error
Random
Error
Description
17900032
17900033
17900034
17900035
17900036
17900037
17900038
0.5, piston PE-HD, cylinder PP,
1 packing, 5 pcs/packing
1.25, piston PE-HD, cylinder PP,
1 packing, 5 pcs/packing
2.5, piston PE-HD, cylinder PP,
1 packing, 5 pcs/packing
5, piston PE-HD, cylinder PP,
1 packing, 5 pcs/packing
12.5, piston PE-HD, cylinder PP,
1 packing, 5 pcs/packing
25, piston PE-HD, cylinder PP,
1 packing, 2pcs/packing with 1 pc
adapter
50, piston PE-HD, cylinder PP,
1 packing, 2pcs/packing with 1 pc
adapter
0.50
1.25
2.50
5.00
12.50
25.00
50.00
10
25
50
100
250
500
1000
20
50
100
200
500
1000
2000
30
75
150
300
750
1500
3000
40
100
200
400
1000
2000
4000
50
125
250
500
1250
2500
5000
± 0.8
± 0.8
± 0.8
± 0.4
± 0.3
± 0.2
± 0.2
≤ 0.7
≤ 0.5
≤ 0.4
≤ 0.3
≤ 0.3
≤ 0.3
≤ 0.2
1 2 3 4 5
48 23 15 11 8
Specifications
Precision Dispenser Tip
 
