SP-UV3102
10.1 inches high resolution TFT colored
capacitive touch screen（1024*600） and
windows graphic interface.
Powerful functions like Photometric measurement, Quantitative measurement, Kinetics, Spectrum scan,
DNA\Protein test, multi-wavelength test, etc
In-house massive memory is capable of saving up to 1024M for test data & working curves.
Various optional accessories, like automatic cell holder, thermostatic automatic sampler, adjustable micro cell
holder, reflection accessory and integrating sphere, etc. which extend the application range of device and
combine the requirements of common samples and special ones.
Supports USB storage. The USB port can be used for data transfer, which is easily exported to Excel for further
processing, analysis and storage.
Socket type deuterium and tungsten lamp can make lamps switching without optics debugging and easy to be
replaced.
Follow GLP/GMP standards, user management, logging, data tracking and exporting, etc.are all available.
•
•
•
•
•
•
•
pectrometer
S
Touch screen double beam
UV Vis spectrophotometer
Features
Optical System
Wavelength Range
Spectral Bandwidth
Wavelength Accuracy
Wavelength Repeatability
Photometric Accuracy
Photometric Repeatability
Photometric Range
Stray Light
Stability
Baseline Flatness
Noise
Work Mode
Scanning Speed
Wavelength Setting
Display
Light Source
Detector
Cuvette Holder
Output
Power Requirements
Dimension[L×W×H]
Weight
Standard Accessaries
Double Beam
190-1100 nm
2.0nm
±[email protected], ±0.3nm@all
≤0.1nm
±0.002A(0～0.5A)±0.003A(0.5A～1A)
±0.001A(0～0.5A)±0.0015A(0.5A～1A)
-0.3～3A,0～9999C(0～9999F)
≤0.03%T @ 220,360nm
≤0.001 A/h/500nm(After 1 hour of preheating)
±0.001A
0.0005A@500nm
T, A, C, E
High | Medium | Slow
Auto
10.1-inch large color touch screen(1024×600)
Tungsten Lamp(Japan HYBEC) | Deuterium Lamp (Milaras)
Imported Silicon Photodiode
Single hole 1cm holder(standard for double beam)
USB Port Printer Port
110/220V,50/60Hz,120W
570mm×440×210mm
20kg
10mm glass cuvette x 4, 10mm quartz cuvette x 2, Power cord, User's Manual , PC software
SP-UV3102
Specifications
10MM water bath 4-position manual
cuvette holder 1cm
(for SP-UV2101/SP-UV2102)
18900336
item No.
1mm(H)*10mm(W)*30mm(L)
(for SP-UV3101/SP-UV3102/
SP-UV5101/SP-UV5102)
Single hole 1cm holder
(for SP-UV3101/SP-UV3102/
SP-UV5101/SP-UV5102)
4 position 5cm holder(1cm-5cm)
(for SP-UV2101/SP-UV2102)
pectrometer
S
18901008
item No.
18901009
item No.
Single hole 5cm holder(1cm-10cm)
(for SP-UV3101/SP-UV3102/
SP-UV5101/SP-UV5102)
18901010
item No.
18204256
item No.
Automatic 8-position cell holder
1cm
(for SP-UV2101/SP-UV2102)
18901013
item No.
Automatic 5-position cell holder
1cm-5cm
(for SP-UV2101/SP-UV2102)
18901014
item No.
Integrating Sphere
95mm(L)* 101mm(W)* 99mm(H)
(for SP-UV3101/SP-UV3102/
SP-UV2101/SP-UV2102)
18901012
item No.
Thin film sample holder
1mm（H）*10mm（W）*30mm（L）
(for SP-UV2101/SP-UV2102)
18901007
item No.
pectrometer
S
Deuterium lamp（A510KU） 10V
(for SP-UV3101/SP-UV3102/
SP-UV2101/SP-UV2102)
18901011
item No.
Tungsten lamp HYBEC
(for SP-UV3101/SP-UV3102/
SP-UV2101/SP-UV2102)
18901382
item No.
Automatic 8-position cell holder
1cm
(for SP-UV3101/SP-UV3102/
SP-UV5101/SP-UV5102)
item No.
Visible light precision filter
440、546、635nm
(for full series)
18901509
item No.
UV-K2Cr2O7
235、257、313、350nm
(for full series)
18901510
item No.
HOMIUM
241、361、417、538、641nm
(for full series)
18901511
item No.
Stray light filter
220nm
(for full series)
18901512
item No.
Stray light filter
360nm
(for full series)
18901513
item No.
Automatic 4-position cell holder
1cm-5cm
(for SP-UV2101/SP-UV2102)
18902175 18902200
item No.
